JC 5030

Product Highlights

  • Multil-functions operation
  • Automatic built in test and self diagnosis
  • Secure access Key
  • Auto archiving and Scan
  • Energy saving design
  • One key Shutdown
  • Drugs and explosives inspection
  • Indication of the date and time
  • Baggage counter
  • System Automatic calibration

General Specification

  • Tunnel Size:505 (W) *305 (H) mm
  • Conveyor Speed: 0.22m/s
  • Conveyor Height (mm): 645mm
  • Conveyor Max Load: 150kg
  • X Ray dose per Inspection: 0.7µGy
  • X Ray Leakage:< 0.05 µGy/h (at the distance 5cm outside)
  • Penetration: 6-8mm steel
  • Wire Resolution: dia 0.101mm copper wire (AWG 40)
  • Spatial resolution: Horizontal:dia 1.3mm, Vertical: dia 1.3mm
  • Power Consumption: max. 500W
  • Noise: 58 dB
  • Film Safety: Guarantee ASA/ISO1600 Film

X-ray Generator Specifications

  • Anode Voltage: 80 KV
  • Anode power: 0.5mA
  • Generate angle: 80 degree upward
  • Generate direct: from bottom to top
  • Cooling / Duty Cycle: Oil Cooling /100%
  • Brand: made by SECUSTAR

Image System Specs

  • X-ray Sensor: L-Shaped Photodiode Array (multi-energetic) , 32bit Deep
  • Image process: High resolution of 1024 * 1280 pixel; Image Grey Level: 4096
  • Image processing function: 1-64times enlargement continuity, Color/BW, negative, high/low ,organic and inorganic penetration, darken/lighten,Local magnification, general enhancement, and pseudo color
  • Image Recall: All preceding images recallable, retrieval and baggage counter auto.
  • Explosives & Narcotics Detection: Explosives & narcotics alarm and highlight according to atomic number signature
  • High density/organic alarm: Impenetrable region alarm and highlight, for possible concealing of threats and contrabands ,organic alarm and high density alarm.
  • Threat Image Projection: Inserting fictional, but realistic images of threat items into baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability
  • Image Archive: Up to 12,0000 images stored automatically, enable transferring to USB disk,
    and converting to JPG, BMP PNG and other general formats
  • Miscellaneous Functions: Time/date display, counters, user management, system-on/X-ray-on timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and system training
  • Network Applications: Multiple remote applications available based on Ethernet LAN and windows platform, such as image centralized storage and identify, recheck workstation, Teamview work.

Operating Environment

  • Operation temperature/Humidity: 0?-45? / 5%-95%(non-condensing)
  • Storage Temperature/Humidity: -40?to 70? / 5%-95%(non-condensing)
  • Operation Power: 220VAC(±10%) 50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
  • UPS: 15mins, 30mins, 60mins etc, Optional

Computer and other

  • Monitor: High Resolution Color, 1280*1024 LCD Accord, 19inch
  • Hard Disk: SEAGATE 64G
  • CPU: Intel Celeron CPU J1800
  • Storage: 4GB
  • Keyboard: self-made professional console
  • Main board: IMX6_mainboard-V030
  • System: Windows 7 , machine with USB ports for real images output

Machine Dimensions (mm)
