JC-700 Explosive & Narcotics Trace Detector

Explosive & Narcotics Trace Detector

Model: JC-700

The JC-700 can detect black powder and all explosives which are prohibited by ICAO.
We adopt PIMS technology (Photoionization Ion Mobility Spectrometry), which is free of radiation hazards.

Key features:

  • High sensitivity: Can detect at least 100 Nanogram black powder, including fireworks and civil homemade explosives
  • High speed Indentify
  • VUV lamp soft ionization technique, non-radioactive
  • Advanced migration tube design ensures high resolution
  • Automatic cleaning system can prevent inject pollution.
  • Renewable gas purification system
  • Database open to user, can add new type explosive
  • TFT color touch screen
  • Dipstick can be reused
  • Support network control and transfer
  • Mass storage, USB port to output data. Printer.

Technical Specification:

  • Source: Vacuum ultra violet ionization source.
  • Explosive identifies: TNT, BP TNP Homemade black powder, gunpowder, ONC HMX , PLX, RDX, PBX, HE, AN, PETN, TATB, C3, C4, EGDN and other explosives.
  • Sampling: dipstick tracking trace particles and absorber
  • Data Library: open to user, can add new type explosive items
  • Alarm way: Sound / light
  • Sensitivity: Mix: Nanogram explosives, even pictogram sulfur
  • Sensitivity: limit 1 Nanogram TNT
  • Identify speed: < 6 seconds
  • Decontamination time: < 4 seconds
  • Warm-up time: < 15 minutes
  • False alarm rate: = 1%
  • Display: TFT color touch screen
  • Consumption: < 300W
  • Power: AC220V 50Hz
  • Operating temperature: -10°C ~ 55°C
  • Net weight: <4.9KG
