PS-300

ModelNo.:PS-300

Walk through metal detector is normally associated with security searching and capable to detect metallic objects on people passing through the door, when we boot , the scanner will be calibration automatically.

PS-300 door frame metal detector adopts advanced DSP technology, Self-testing function, 8 pcs big plastic screws to fix control box with panels. The gate made in waterproof material used outdoor  (IP65 level)

Main Characteristics

  • 18 zone detection precisely, multi-zones detection alarm separately
  • LED digital display with function press keys, auto-count
  • It is able to detect ferrous and non-ferrous articles
  • The body shape LED with 18 zone to display detection alarm
  • Automatically count passengers and alarm times
  • Self-diagnostic procedures and calibration automatically
  • DSP digital technology, Sound alarm, volume adjustable
  • Modular structure is easy to do after sales service
  • It is Harmless to pregnant woman and heart pacemaker
  • Tamper-proof, operate program is protected by password
  • One power port on head and two power ports in feet end
  • MBSU battery backup, in time power transfer (optional)
  • Remote controller for 30meter distance remote control (optional)
  • Password protection for preventing parameter program changed
  • Led alarm bars built in front of door panels that is for accurate detection and alarm display of metals
  • Sensitivity adjustable, overall 0-199 level, each zone also 0-199 level sensitivity
  • The frequency adjustable ,100units gates work side by side without any interference

Technical Specification

  • Electric current: AC 210V~240V 50/60Hz
  • Power Consumption: Max 15W Work environment: -20~+45
  • Gross Weight: 65kg
  • Outerframe : 2220mm(h ) x 800mm(w ) x 580mm(d)
  • Innerframe: 2010mm(h) x700mm(w) x 500mm(d)
  • Control Box Package Size: 760mm(L) x 380mm(W) x 260mm (H)
  • Door Panel Package Size: 2290mm(L) x 560mm(W) x 180mm (H)
