ModelNo.: PS-300 2024
Walk through metal detector is normally associated with security searching and capable to detect metallic objects on people passing through the door,
when we boot , the scanner will be calibration automatically.
JC-300 door frame metal detector adopts advanced DSP technology, IP66 Self-testing function, 8 pcs big plastic screws to fix control box with panels.
Main Characteristics
- 18 zone detection precisely, multi-zones detection alarm separately
- LED digital display with function press keys, auto-count
- It is able to detect ferrous and non-ferrous articles
- The body shape LED with 18 zone to display detection alarm
- Automatically count passengers and alarm times
- Self-diagnostic procedures and calibration automatically
- DSP digital technology, Sound alarm, volume adjustable
- Modular structure is easy to do after sales service
- It is Harmless to pregnant woman and heart pacemaker
- Tamper-proof, operate program is protected by password
- One power port on head and two power ports in feet end
- MBSU battery backup, in time power transfer (optional)
- Network interface on computer for data transmission (optional)
- Password protection for preventing parameter program changed
- Led alarm bars built in front of door panels that is for accurate detection and alarm display of metals
- Sensitivity adjustable, overall 0-199 level, each zone also 0-199 level sensitivity
- The frequency adjustable ,100units gates work side by side without any interference
Technical Specification
- Electric current: AC 210V~240V 50/60Hz
- Power Consumption: Max 15W
- Work environment: -20°C to 60°C
- Outerframe : 2220mm(h ) x 800mm(w ) x 580mm(d)
- Innerframe: 2010mm(h) x700mm(w) x 500mm(d)
- Control Box Package Size: 760mm(L) x 380mm(W) x 260mm (H)
- Door Panel Package Size: 2290mm(L) x 560mm(W) x 180mm (H)
- Gross Weight: 65kg
